GL600S Steel Crawler Type Water Well Drill/Drilling Rig with DTH Hammer or Mud Pump for Drilling

1
MOQ
negotiable
価格
GL600S Steel Crawler Type Water Well Drill/Drilling Rig with DTH Hammer or Mud Pump for Drilling
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
名前: GL600S クローラータイプ DTH 井戸掘削装置ボーリング穴用機械
キーワード: ボーリング孔用ドリルリグマシン
深さ: 600m
掘削直径: 105~500mm
空気圧: 1.05～4.5MPa
棒長: 3m,6m
ドリルロッド径: 89-102-114mm
持ち上げる力: 35t
エンジン: 176kw
寸法: 5800*2200*2550mm
ハイライト:

steel crawler water well drill

,

DTH hammer drilling rig

,

mud pump well drilling rig
基本情報
起源の場所: 中国
ブランド名: Glorytek
証明: CE
モデル番号: GL600S
お支払配送条件
パッケージの詳細: 標準輸出パッケージ
受渡し時間: 20日
支払条件: T/T、L/C、Western Union、MoneyGram、D/P、D/A
供給の能力: 40sets/month
製品の説明
GL600S Crawler Type Water Well Drill/Drilling Rig for 600m Depth and 105-500mm Diameter
GL600S Track Mounted DTH Water Well Drill Rig Machines For Borehole
The GL600S crawler water well drill rig machine is designed for geothermal, industrial, and agricultural drilling applications. Featuring a durable steel crawler chassis for easy mobility and a powerful 176kw diesel engine, this rig delivers exceptional drilling capacity.
Technical Specifications
Parameter Value
Max Drilling Depth (m) 600
Drilling Diameter (mm) 105-500
Air Pressure (Mpa) 1.05-4.5
Air consumption 16-60m³/min
Rod Length (m) 3.0 / 6.0
Rod Diameter (mm) 89-102-114
Main Shaft Pressure (T) 14
Lifting Force (T) 35
Fast lifting speed 24m/min
Rotary Torque (N.m) 13000
Rotary Speed (r/min) 30/170
Winch Lifting Force (T) 5
High leg stroke (M) 1.5-1.65
Moving Speed (km/h) 3.5
Uphill Angle (°) 21
Weight of the Rig (T) 13
Engine 191KW
Overall Dimensions (MM) 5800*2200*2550
Working Condition loose layer or bedding rock
Drilling Method Top Hammer Hydraulic Rotating and feeding, Down the hole hammer or mud pump drilling
GL600S Steel Crawler Type Water Well Drill/Drilling Rig with DTH Hammer or Mud Pump for Drilling 0
GL600S Steel Crawler Type Water Well Drill/Drilling Rig with DTH Hammer or Mud Pump for Drilling 1
GL600S Steel Crawler Type Water Well Drill/Drilling Rig with DTH Hammer or Mud Pump for Drilling 2
Customer Visiting
GL600S Steel Crawler Type Water Well Drill/Drilling Rig with DTH Hammer or Mud Pump for Drilling 3
Company Profile
About Glorytek Industry
Glorytek Industry (Beijing) Co., Ltd is a professional manufacturer and supplier of drilling equipment and drilling tools with over 20 years of experience. Supported by an experienced R&D team and engineers, we successfully complete projects according to clients' requirements. As an important member of "Sundrill Corporation," our 250,000 square meter facility includes machining machinery, CNC processing centers, friction welding machines, and testing equipment. With over 200 sets of equipment and 600 employees, our products have been exported to more than 60 countries worldwide.
Warranty Information
For drill rig main parts, if quality issues are confirmed, we provide free replacement within one year after shipping.
