| Model | Free Air Delivery (m³/min) | Working Pressure (bar) | Noise Level (dB) | Weight (kg) | Engine Power (kW/HP) |
|---|---|---|---|---|---|
| LUY025-7 | 2.5 | 7 | <70 | 556 | 19.4/26 |
| LUY036-7 | 3.6 | 7 | <80 | 652 | 22/30 |
| LUY050-7 | 5.0 | 7 | <70 | 688 | 32/43 |
| LUY055-7 | 5.5 | 7 | 77±3 | 960 | 36/49 |
| LUY079-7 | 7.9 | 7 | 78±3 | 1500 | 60/80 |
| LUY085-14 | 8.5 | 14 | 78±3 | 1680 | 97/130 |
| Model | Free Air Delivery (m³/min) | Working Pressure (bar) | Noise Level (dB) | Weight (kg) | Engine Power (kW/HP) |
|---|---|---|---|---|---|
| LUY120-14 | 12 | 14 | 78±3 | 3100 | 132/180 |
| LUY130-17 | 13 | 17 | 79±3 | 3500 | 153/205 |
| LUY170-13 | 17 | 15 | 79±3 | 3500 | 179/240 |
| LUY250-12 | 25 | 12 | 79±3 | 4600 | 232/311 |
| LUY270-10 | 27 | 10 | 79±3 | 5100 | 194/260 |
| LUY330-21 | 33 | 21 | 74±3 | 5750 | 354/475 |
| Specification | Model 26/20 | Model 33/25 |
|---|---|---|
| Nominal Volume Flow (m³/min) | 26 | 33 |
| Rated Discharge Pressure (MPa) | 2.0 | 2.5 |
| Unit Weight (kg) | 4500 | 6800 |
| Dimensions (mm) | 4600×1950×2850 | 4700×2100×2500 |
| Diesel Engine Power (HP) | 360 | 550 |
| Fuel Tank Capacity (L) | 400 | 600 |
| Model | Free Air Delivery (m³/min) | Pressure (bar) | Motor Power (kW) | Weight (kg) |
|---|---|---|---|---|
| LUY100D-7 | 10 | 7 | 55 | 1800 |
| LUY110D-10 | 11 | 10 | 75 | 1920 |
| LUY130D-7 | 13 | 7 | 75 | 1920 |
| LUY165D-7 | 16.5 | 7 | 90 | 3195 |
| LUY203D-7 | 20.3 | 7 | 110 | 3220 |
| Model | Free Air Delivery (m³/min) | Pressure (bar) | Motor Power (kW) | Weight (kg) |
|---|---|---|---|---|
| LUY210D-10 | 21 | 10 | 132 | 4360 |
| LUY230D-8.5 | 23 | 8.5 | 132 | 4360 |
| LUY250D-10 | 25 | 10 | 160 | 4500 |
| LUY290D-21 | 29 | 21 | 250 | 4900 |
